B: Using a Model 590 C-V Analyzer Model 4200A-SCS Parameter Analyzer
B-36 4200A-901-01 Rev. C / February 2017
The return values from status can be:
• 0: OK.
• -10000 (INVAL_INST_ID): The specified instrument ID does not exist. This generally means
that there is no instrument with the specified ID in your configuration.
• -10001 (INVAL_PIN_SPEC): An invalid DUT pin number was specified.
• -10003 (NO_SWITCH_MATRIX): No switch matrix was found.
• -10004 (NO_MATRIX_CARDS): No matrix cards were found.
• -10020 (COMP_FILE_ACCESS_ERR): There was an error accessing the specified cable
compensation file.
• -10021 (COMP_FILE_NOT_EXIST): The specified compensation file does not exist.
• -10022 (KI590_NOT_IN_KCON): There is no CMTR defined in the system configuration.
Also see
CableCompensate590 user module (on page B-12)
