D: Using a Model 82 C-V System Model 4200A-SCS Parameter Analyzer
D-46 4200A-901-01 Rev. C / February 2017
The following table lists the valid range values for Range590.
Range590 valid range values
Range 100 kHz 1 MHz
2 pF / 2 µs 20 pF / 200 µs
2 nF / 2 ms 2 nF / 20 ms
If CabCompFile does not exist, or if there is no path specified (null string), the default compensation
parameters are used. When entering the path, be sure to use two \ characters to separate each
directory. For example, if your cable file is in:
C:\calfiles\590cal.dat
You would enter:
C:\\calfiles\\590cal.dat
The return values from status can be:
• 0: OK.
• -10000 (INVAL_INST_ID): The specified instrument ID does not exist
• -10020 (COMP_FILE_ACCESS_ERR): There was an error accessing the specified cable
compensation file
• -10021 (COMP_FILE_NOT_EXIST): The specified compensation file does not exist
• -10023 (KI590_MEAS_ERROR): A measurement error occurred
• -10090 (GPIB_ERROR_OCCURRED): A GPIB communications error occurred
• -10091 (GPIB_TIMEOUT): A timeout occurred during communications
• -10100 (INVAL_PARAM): An invalid input parameter is specified
• -10101 (ARRAY_SIZE_TOO_SMALL): The specified value for CHF_ArrSize,
G_or_R_ArrSize, V_ArrSize, CQS_ArrSize, or QT_ArrSize was too small for the number
of steps in the sweep
• -10102 (ERROR_PARSING): There was an error parsing the 590 response
• -10104 (USER_CANCEL): The user canceled the correction procedure
• -10045 (KI82_NOT_IN_KCON): KI82 is not in KCon
Procedure
1. If set, you are prompted to open the circuit so that an offset capacitance measurement can be
made.
2. If a cable compensation file is specified, the compensation information in that file for the selected
range and frequency will be loaded. If not, instrument default compensation is used.
3. A simultaneous C-V sweep is made.
Also see
None
