Appendix

H: Using a Micromanipulator 8860 Prober Model 4200A-SCS Parameter Analyzer

Reference Manual

H-10 4200A-901-01 Rev. C / February 2017

Figure 691: pcNav window

The OVD button toggles the state of the overdrive (on or off).

3. Click the Home button on the Tools panel of the pcNav window. The Initialize positioners to

Home window opens. See the following two figures.

Figure 692: Home button
