Keithley 4200A-SCS Reference Manual

Appendix
H: Using a Micromanipulator 8860 Prober Model 4200A-SCS Parameter Analyzer
Reference Manual
H-20 4200A-901-01 Rev. C / February 2017
3. Select the spline pattern. The icon of the active spline pattern is transferred to the Edit Die
Program Parameters dialog box, as shown in the following figure.
Figure 713: Edit Die Program Parameters window
4. Click Save on the Die Program Tools window.
5. To open an existing program listing file, click the pcWfr Open button on the Die Program Tools
window. Select the file and click OK.
Before starting testing, physically align the pins over the reference die.
