Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Section 5: Pulse measure and pulse generator units
4200A-901-01 Rev. C / February 2017 5-65
Test device resistance
(Ω)
Voltage (V)* Current (A)*
1
0.196
0.196
5 0.909 0.182
10
1.667
0.167
25 3.333 0.133
50
5
0.100
100 6.667 0.067
250
8.333
0.033
1 k 9.524 0.0095
10 k
9.950
0.000995
* Approximate value; does not account for interconnect losses.
Available I and V for the high voltage (20 V) range of the Keithley pulse card
Maximum I and V versus resistance
Test device resistance
(Ω)
Voltage (V)* Current (A)*
1
0.784
0.784
5
3.636
0.727
10
6.667
0.667
25
13.333
0.533
50
20
0.400
100
26.667
0.267
250
33.333
0.133
1 k
38.095
0.038
10 k
39.801
0.00398
*Approximate value; does not account for interconnect losses.
