Keithley 4200A-SCS Reference Manual

Section
6: Clarius Model 4200A-SCS Parameter Analyzer
Reference Manual
6-78 4200A-901-01 Rev. C / February 2017
PMU measurement status codes
Code
letter
Summary or description Value
A
Load-line effect compensation (LLEC)
and sweep
0 = LLEC disabled, sweep not skipped
1 = LLEC failed, sweep not skipped
3 = LLEC successful, sweep not skipped
4 = LLEC disabled, sweep skipped
5 = LLEC failed, sweep skipped
7 = LLEC successful, sweep skipped
B
RPM mode settings
0 = No RPM
1 = RPM
2 = Bypass; PMU
3 = Bypass; SMU
4 = Bypass; CVU
C
Reserved for future use
Always 0
D Measurement type
1 = Spot mean
2 = Waveform
E
Current threshold, voltage threshold,
power threshold, and source
compliance
0 = None
1 = Source compliance
2 = Current threshold reached or surpassed
4 = Voltage threshold reached or surpassed
8 = Power threshold reached or surpassed
F
Voltage measure overflow and current
measure overflow
0 = No overflow
1 = Negative voltage overflow
2 = Positive voltage overflow
4 = Negative current overflow
5 = Negative voltage and negative current
overflow
6 = Positive voltage and negative current overflow
8 = Positive current overflow
9 = Negative voltage and positive current overflow
A = Positive voltage and positive current overflow
G Current measure range
0 = 100 nA (RPM only)
1 = 1 µA (RPM only)
2 = 10 µA (RPM only)
3 = 100 µA
4 = 1 mA (RPM only)
5 = 10 mA
6 = 200 mA
7 = 800 mA
H
Channel number and voltage measure
range
1 = Ch1, 10 V
2 = Ch2, 10 V
5 = Ch1, 40 V
6 = Ch2, 40 V
