Keithley 4200A-SCS

To Next Page

To Previous Page

Section

6: Clarius Model 4200A-SCS Parameter Analyzer

Reference Manual

6-206 4200A-901-01 Rev. C / February 2017

Graph tab fit Formulator fits that return the corresponding fit line and fit parameters

Fit line Fit parameter "a"

Fit parameter

"b"

Fit parameter

"xint"

Linear

LINFIT

LINFITYINT

LINFITSLP

LINFITXINT

Regression

REGFIT

REGFITYINT

REGFITSLP

REGFITXINT

Exponential

EXPFIT

EXPFITA

EXPFITB

Not applicable

Log

LOGFIT

LOGFITA

LOGFITB

Not applicable

Tangent

TANFIT

TANFITYINT

TANFITSLP

TANFITXINT

However, the Graph and Formulator tools each provide specific advantages. For example, Graph fits

help you visualize "what if" trials on various data points, while Formulator fit results can be used

directly in other calculations.

Line fit examples

The following figures illustrate the linear and regression line fit types.

Figure 363: Linear fit example
