6: Clarius Model 4200A-SCS Parameter Analyzer
6-210 4200A-901-01 Rev. C / February 2017
Use existing cursors for line fits
To use existing cursors for line fits:
1. Right-click a cursor. The Cursor dialog box for the selected cursor opens, as shown below.
Figure 367: Cursor # dialog box
2. Select Fit # On.
3. Select Properties under Fit # On.
4. Refer to Perform line fits (on page 6-207
) for information on the options.
View information about the cursor-specified data
When you select a cursor, Clarius displays the following information next to the cursor:
• The cursor number.
• The data series.
• The Run worksheet row number.
• The cursor coordinates.
