6: Clarius Model 4200A-SCS Parameter Analyzer
6-212 4200A-901-01 Rev. C / February 2017
An example of the zoom area in the graph above is shown here.
Figure 369: Zoom in on an area of the graph - results
To make the graph smaller, right-click the graph and select Zoom Out.
Zooms are temporary characteristics of the graph and cannot be saved.
Add a comment
You can add a comment that appears on the graph.
To add a comment:
1. Right-click the graph.
2. Select Comment. The Comment Properties dialog box is displayed, as shown here.
Figure 370: Graph Comment Properties dialog box
