Keithley 4200A-SCS Reference Manual

Section
9: Keithley External Control Interface (KXCI) Model 4200A-SCS Parameter Analyzer
Reference Manual
9-20 4200A-901-01 Rev. C / February 2017
VP and IP
This command sets up the VAR2 step sweep.
Usage
AA ±BBB.BBBB, ±CCC.CCCC, DD, ±EEE.EEEE
AA ±BBB.BBBB, ±CCC.CCCC, DD, ±EEE.EEEE, FF
AA
The source mode:
• VP: Voltage source (SMU or VS1...VS8)
•
IP: Current source (SMU only)
BBB.BBBB
Start value:
• Voltage source: −210.00 V to +210.00 V
• Current source, 4200-SMU: −0.1050 A to +0.1050 A
• Current source, 4210-SMU: −1.0500 A to +1.0500 A
CCC.CCCC
Step value:
• Voltage source: −210.00 V to +210.00 V
• Current source, 4200-SMU: −0.1050 A to +0.1050 A
•
Current source, 4210-SMU:
−
1.0500 A to +1.0500 A
DD
Number of steps: 1 to 32
EEE.EEEE
Compliance value (see Details):
• Voltage source: −210.00 V to +210.00 V
• Current source, 4200-SMU: −0.1050 A to +0.1050 A
•
Current source, 4210-SMU:
−
1.0500 A to +1.0500 A
FF
VAR2 source stepper index: 1 to 4 (see Details)
