-SCS Parameter Analyzer Reference Manual Section 9: Keithley External Control Interface (KXCI)
4200A-901-01 Rev. C / February 2017 9-31
LI
This command enables voltage and current functions to be measured when the 4200A-SCS is in list display
mode.
Usage
LI 'AAAAAA'
LI 'AAAAAA', 'AAAAAA'
LI 'AAAAAA', 'AAAAAA', 'AAAAAA'
LI 'AAAAAA', 'AAAAAA', 'AAAAAA', 'AAAAAA'
LI 'AAAAAA', 'AAAAAA', 'AAAAAA', 'AAAAAA', 'AAAAAA'
LI 'AAAAAA', 'AAAAAA', 'AAAAAA', 'AAAAAA', 'AAAAAA', 'AAAAAA'
A name assigned for
,
, or
; see channel definition page (
)
Details
When the 4200A-SCS is in the list display mode (DM2 asserted), the LI command enables functions
to be measured in a test sequence. To enable a function, include the SMU channel name (as
assigned by the CH command), voltage source name (as assigned by the VS command), or the
voltmeter name (as assigned by the VM command) in the command string. The DE page is used to
assign names to voltage and current functions.
Only functions that are specified (enabled) are measured. Data sheet columns for disabled functions
are not shown.
Example
Assume the following names have been assigned using the DE page for SMU channel 1 (CH1):
• Voltage is named V1
• Current is named I1
• Voltage source is named VS1
The command string enables the above functions for a test sequence.
Also see
Channel definition page (DE) (on page 9-13)
DM (on page 9-30)
