Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Section 9: Keithley External Control Interface (KXCI)
4200A-901-01 Rev. C / February 2017 9-61
PO
This command sets the output state (on or off) and mode (normal or complement) independently for each
channel.
Usage
PO A, B, C
A
Pulse card channel: 1 to 8; the largest value is the number of channels in the
system
B
Output state:
• Off: 0 (default)
• On:
1
C
Output mode:
• Normal: 0 (default)
• Complement:
1
Corresponding LPT library functions
pulse_output (on page 13-146)
pulse_output_mode (on page 13-147)
Example
PO 1, 1, 1
This command string turns on channel 1 of pulse card 1 and selects complement pulse output mode.
Also see
None
PS
This command resets both channels of the selected pulse card to the default settings.
Usage
PS A
A
Pulse card channel: 1 to 8; the largest value is the number of channels in the
system
Corresponding LPT library functions
pulse_init (on page 13-144)
Example
PS 3
This command string resets pulse card 2.
Also see
None
