Model 4200A

-SCS Parameter Analyzer Reference Manual Section 9: Keithley External Control Interface (KXCI)

4200A-901-01 Rev. C / February 2017 9-71

:CVU:STANDBY

This command configures the selected CVU card to disable DC bias at the end of a test or leave it active.

Usage

:CVU:STANDBY state

state

The state of the CVU card at the end of the test:

• Disable the DCV output: 1

• Leave the state active:

Also see

None

:CVU:DATA:Z?

This command queries the Z measurement of the CVU when a test is complete.

Usage

:CVU:DATA:Z?

Details

Z measurements are returned as semi-colon delimiter pairs. Each reading is then delimited with

commas.

Also see

None

:CVU:DATA:VOLT?

This command queries the voltage measurement of the CVU once a test is complete.

Usage

:CVU:DATA:VOLT?

Also see

None

:CVU:DATA:FREQ?

This command queries the frequency measurement of the CVU once a test is complete.

Usage

:CVU:DATA:FREQ?

Also see

None
