Section
9: Keithley External Control Interface (KXCI) Model 4200A-SCS Parameter Analyzer
Reference Manual
9-76 4200A-901-01 Rev. C / February 2017
:CVU:LENGTH
This command selects the cable length for the specified CVU card.
Usage
:CVU:LENGTH len
len
The cable length:
• 0: 0 m (no cable compensation)
• 1.5: 1.5 m CVU cable
• 3.0: 3.0 m CVU cable
• 4.0: Custom
• 5.0: 1.5 m CVIV cable; 2-wire mode
• 6.0: 1.5 m CVU to CVIV cable with 0.75 m CVIV to DUT cable; 4-wire mode
• 7.0: Blue 1.5 m CVU to CVIV cable with 0.61 m CVIV to DUT cable; 4-wire
mode
Also see
None
:CVU:CORRECT
This command enables or disables open, short, and load correction for the specified CVU card.
Usage
:CVU:CORRECT open, short, load
open
off: 0
on: 1
short
off:
0
on: 1
load
off: 0
on:
1
Details
Each of the parameters is a Boolean (0 = off, 1 = on).
Also see
None
:CVU:CABLE:COMP:OPEN
This command performs open compensation and collects the open compensation cable data for the CVU.
Usage
:CVU:CABLE:COMP:OPEN
Also see
Connection compensation (on page 4-10)
