13: LPT library function reference Model 4200A-SCS Parameter Analyzer
13-104 4200A-901-01 Rev. C / February 2017
Data retrieval options for pulse_fetch
There are two options to retrieve data:
• Wait until the test is completed
• Retrieve blocks of data while the test is running
Because pulse_exec is a non-blocking command, the running user test module (UTM) will continue
after it is called to start the test. This means that the program will not automatically pause to allow the
pulse-measure test to finish.
The programmer must ensure that the test program does not finish or return to Clarius before the
test is complete. Erroneous results and damage to test devices may occur.
If pulse_fetch is inadvertently called before the test is completed, the data buffer may not fill with
all the requested readings. Array entries are designated as zero for test data that is not yet available.
Wait until the test is complete before retrieving data
An effective method to pause the program is to monitor the status of the test by using a while loop
to check the returned value of pulse_exec_status. When the test is completed, the program drops
out of the loop and calls pulse_fetch to retrieve all the test data. The following program fragment
shows how to use a while loop.
Program fragment 1
// Code to configure the PMU test here
// Start the test (no analysis)
pulse_exec(0);
// while loop and short delay (10 ms)
while (pulse_exec_status(&elapsedt) == 1)
{
Sleep(10);
}
// Retrieve all data
status = pulse_fetch(PMU1, 1, 0, 49, Drain_Vmeas, Drain_Imeas, NULL, NULL);
// Code for data handling here
After all the data is retrieved, it can be analyzed, manipulated and then posted into the Clarius
Analyze sheet. Use the PostDataDouble or PostDataDoubleBuffer command to post the data.
