The figure below shows example a waveform measurement with pre-data and post-data. Pre-data is
extra data taken before the rise time of the pulse; post-data is extra data taken after the fall time.
Figure 505: Waveform measurements with pre-data and post-data
Use the pulse_sample_rate command to set the sampling rate for pulse measurements.
Before calling the pulse_meas_timing command, use the pulse_meas_sm or pulse_meas_wfm
command to configure the measurement type.
Also see
Measurement timing (on page 5-74)
Measurement types (on page 5-70)
pulse_meas_sm (on page 13-108)
pulse_sample_rate (on page 13-116)
pulse_meas_wfm (on page 13-111)
