13: LPT library function reference Model 4200A-SCS Parameter Analyzer
13-136 4200A-901-01 Rev. C / February 2017
Supported pulse card getstatus query parameters
Parameter
Comment
General parameters:
Pulse period value in seconds
Channel-based parameters:
Channel 1 range value in volts (5.0 or 20.0)
Channel 2 range value in volts (5.0 or 20.0)
Channel 1 rise time value in seconds
Channel 2 rise time value in seconds
Channel 1 fall time value in seconds
Channel 2 fall time value in seconds
Channel 1 pulse width value in seconds
Channel 2 pulse width value in seconds
Channel 1 pulse high level value in volts
Channel 2 pulse high level value in volts
Channel 1 pulse low level value in volts
Channel 2 pulse low level value in volts
Pulse delay Channel 1 pulse delay from trigger value in seconds
Channel 2 pulse delay from trigger value in seconds
Channel 1 current Limit value in amps
Channel 2 current Limit value in amps
Channel 1 burst count value
Channel 2 burst count value
Channel 2 test status
Channel 1 DC output value
Channel 2 DC output value
Channel 1 pulse load value
Channel 2 pulse load value
Also see
getinstid (on page 13-18)
