Chapter 5
124 MIPS R4000 Microprocessor User's Manual
Reset Exception
Cause
The Reset exception occurs when the ColdReset*
†
signal is asserted and
then deasserted. This exception is not maskable.
Processing
The CPU provides a special interrupt vector for this exception:
• location 0xBFC0 0000 in 32-bit mode
• location 0xFFFF FFFF BFC0 0000 in 64-bit mode
The Reset vector resides in unmapped and uncached CPU address space,
so the hardware need not initialize the TLB or the cache to process this
exception. It also means the processor can fetch and execute instructions
while the caches and virtual memory are in an undefined state.
The contents of all registers in the CPU are undefined when this exception
occurs, except for the following register fields:
• In the Status register, SR and TS are cleared to 0, and ERL and
BEV are set to 1. All other bits are undefined.
• Config register is initialized with the boot mode bits read from
the serial input (see Figure 5-14).
• The Random register is initialized to the value of its upper
bound.
• The Wired register is initialized to 0.
• The EW bit in the CacheErr register is cleared (R4400 only).
Reset exception processing is shown in Figure 5-14.
Servicing
The Reset exception is serviced by:
• initializing all processor registers, coprocessor registers, caches,
and the memory system
• performing diagnostic tests
• bootstrapping the operating system
† In the following sections—indeed, throughout this book—a signal followed by an asterisk,
such as Reset*, is low active.
