Implementation and Revision Register, (FCR0)
The read-only Implementation and Revision register (FCR0) specifies the
implementation and revision number of the FPU. This information can
determine the coprocessor revision and performance level, and can also be
used by diagnostic software.
Figure 6-3 shows the layout of the register; Table 6-2 describes the
Implementation and Revision register (FCR0) fields.
Figure 6-3 Implementation/Revision Register
Table 6-2 FCR0 Fields
The revision number is a value of the form y.x, where:
• y is a major revision number held in bits 7:4.
• x is a minor revision number held in bits 3:0.
The revision number distinguishes some chip revisions; however, MIPS
does not guarantee that changes to its chips are necessarily reflected by the
revision number, or that changes to the revision number necessarily reflect
real chip changes. For this reason revision number values are not listed,
and software should not rely on the revision number to characterize the
chip.
Field Description
Imp Implementation number (0x05)
Rev Revision number in the form of y.x
0
Reserved. Must be written as zeroes, and returns zeroes
when read.
16 15 7
Implementation/Revision Register (FCR0)
31 0
16
Rev
88
8
0 Imp
