Table 3-2 Pipeline Interlocks
Exception Conditions
When an exception condition occurs, the relevant instruction and all those
that follow it in the pipeline are cancelled. Accordingly, any stall
conditions and any later exception conditions that may have referenced
this instruction are inhibited; there is no benefit in servicing stalls for a
cancelled instruction.
After instruction cancellation, a new instruction stream begins, starting
execution at a predefined exception vector. System Control Coprocessor
registers are loaded with information that identifies the type of exception
and auxiliary information such as the virtual address at which translation
exceptions occur.
Interlock Description
ITM Instruction TLB Miss
ICM Instruction Cache Miss
CPBE Coprocessor Possible Exception
SXT Integer Sign Extend
STI Store Interlock
DCM Data Cache Miss
WA Watch Address Exception
LDI Load Interlock
MultB Multiply Unit Busy
DivB Divide Unit Busy
MDOne Mult/Div One Cycle Slip
ShSlip Var Shift or Shift > 32 bits
FCBsy FP Busy
