CPU Exception Processing
Status Register Modes and Access States
Fields of the Status register set the modes and access states described in the
sections that follow.
Interrupt Enable: Interrupts are enabled when all of the following
conditions are true:
• IE = 1
• EXL = 0
• ERL = 0
If these conditions are met, the settings of the IM bits enable the interrupt.
Operating Modes: The following CPU Status register bit settings are
required for User, Kernel, and Supervisor modes (see Chapter 4 for more
information about operating modes).
• The processor is in User mode when KSU = 10
2
, EXL = 0, and
ERL = 0.
• The processor is in Supervisor mode when KSU = 01
2
, EXL = 0,
and ERL = 0.
• The processor is in Kernel mode when KSU = 00
2
, or EXL = 1,
or ERL = 1.
32- and 64-bit Modes: The following CPU Status register bit settings select
32- or 64-bit operation for User, Kernel, and Supervisor operating modes.
Enabling 64-bit operation permits the execution of 64-bit opcodes and
translation of 64-bit addresses. 64-bit operation for User, Kernel and
Supervisor modes can be set independently.
• 64-bit addressing for Kernel mode is enabled when KX = 1.
64-bit operations are always valid in Kernel mode.
• 64-bit addressing and operations are enabled for Supervisor
mode when SX = 1.
• 64-bit addressing and operations are enabled for User mode
when UX = 1.
Kernel Address Space Accesses: Access to the kernel address space is
allowed when the processor is in Kernel mode.
Supervisor Address Space Accesses: Access to the supervisor address
space is allowed when the processor is in Kernel or Supervisor mode, as
described above in the section above titled, Operating Modes.
