MIPS R4000 Microprocessor User's Manual 259
Cache Organization, Operation, and Coherency
11.6 Cache Write Policy
The R4000 processor manages its primary and secondary caches by using
a write-back policy; that is, it stores write data into the caches, instead of
writing it directly to memory.
†
Some time later this data is independently
written into memory. In the R4000 implementation, a modified cache line
is not written back to memory until the cache line is replaced either in the
course of satisfying a cache miss, or during the execution of a Write-back
CACHE instruction.
If a primary cache line is in either the dirty exclusive or shared state and
that cache line has been modified (the W bit is set), the processor writes
this cache line back to memory (or the secondary cache, if it is present)
when the line is replaced, either in the course of satisfying a cache miss or
during the execution of a Write-back or Write-back Invalidate CACHE
instruction.
If a secondary cache line is in either the dirty exclusive or dirty shared
state, the processor writes this cache line back to memory when the line is
replaced, either in the course of satisfying a cache miss or during the
execution of a Write-back CACHE instruction.
Many systems, in particular multiprocessor systems, or systems
employing I/O devices that are capable of DMA, require the system to
behave as if the caches are always consistent both with memory and with
each other. Schemes for maintaining consistency between more than one
cache, or between caches and memory, are defined by the system cache
coherency protocols (see the section titled Cache Coherency Overview
later in this chapter). In the R4000 system, when the content of a cache line
is inconsistent with memory, it is classified as dirty and is written back to
memory according to the rules of the cache write-back policy.
When the processor writes a cache line back to memory, it does not
ordinarily retain a copy of the cache line, and the state of the cache line is
changed to invalid. However, there is one exception. The processor
retains a copy of the cache line if a cache line is written back by the Hit
Write-back cache instruction. The processor changes the retained cache
line state to either clean exclusive if the secondary cache state was dirty
exclusive before the write, or shared if the secondary cache state was dirty
shared before the write. The processor signals this line retention during a
write by setting SysCmd(2) to a 1, as described in Chapter 12.
† An alternative to this is a write-through cache, in which information is written
simultaneously to cache and memory.
