Initialization Interface
9.2 Reset Signal Description
This section describes the three reset signals, VCCOk, ColdReset*, and
Reset*.
VCCOk: When asserted
†
, VCCOk indicates to the processor that the +5
volt power supply (Vcc) has been above 4.75 volts for more than 100
milliseconds (ms) and is expected to remain stable. The assertion of
VCCOk initiates the reading of the boot-time mode control serial stream
(described in Initialization Sequence, in this chapter).
ColdReset*: The ColdReset* signal must be asserted (low) for either a
power-on reset or a cold reset. The clocks SClock, TClock, and RClock
begin to cycle and are synchronized with the deasserted edge (high) of
ColdReset*. ColdReset* must be deasserted synchronously with
MasterClock.
Reset*: the Reset* signal must be asserted for any reset sequence. It can
be asserted synchronously or asynchronously for a cold reset, or
synchronously to initiate a warm reset. Reset* must be deasserted
synchronously with MasterClock.
ModeIn: Serial boot mode data in.
ModeClock: Serial boot mode data out, at the MasterClock frequency
divided by 256 (MasterClock/256).
† Asserted means the signal is true, or in its valid state. For example, the low-active Reset*
signal is said to be asserted when it is in a low (true) state; the high-active VCCOk signal
is true when it is asserted high.
