MIPS R4000 Microprocessor User's Manual 213
Initialization Interface
9
This chapter describes the R4000 Initialization interface. This includes the
reset signal description and types, initialization sequence, with signals
and timing dependencies, and boot modes, which are set at initialization
time.
Signal names are listed in bold letters—for instance the signal VCCOk
indicates +5 voltage is stable. Low-active signals are indicated by a
trailing asterisk, such as ColdReset*, the power-on/cold reset signal.
