MIPS R4000 Microprocessor User's Manual 167

Floating-Point Unit

6.6 Floating-Point Instruction Set Overview

All FPU instructions are 32 bits long, aligned on a word boundary. They

can be divided into the following groups:

• Load, Store, and Move instructions move data between

memory, the main processor, and the FPU General Purpose

registers.

• Conversion instructions perform conversion operations

between the various data formats.

• Computational instructions perform arithmetic operations on

ﬂoating-point values in the FPU registers.

• Compare instructions perform comparisons of the contents of

registers and set a conditional bit based on the results.

• Branch on FPU Condition instructions perform a branch to the

speciﬁed target if the speciﬁed coprocessor condition is met.

In the instruction formats shown in Tables 6-9 through 6-12, the fmt

appended to the instruction opcode specifies the data format: S specifies

single-precision binary floating-point, D specifies double-precision binary

floating-point, W specifies 32-bit binary fixed-point, and L specifies 64-bit

(long) binary fixed-point.

Table 6-9 FPU Instruction Summary: Load, Move and Store Instructions

OpCode Description

LWC1 Load Word to FPU

SWC1 Store Word from FPU

LDC1 Load Doubleword to FPU

SDC1 Store Doubleword From FPU

MTC1 Move Word To FPU

MFC1 Move Word From FPU

CTC1 Move Control Word To FPU

CFC1 Move Control Word From FPU

DMTC1 Doubleword Move To FPU

DMFC1 Doubleword Move From FPU
