MIPS R4000 Microprocessor User's Manual 127
CPU Exception Processing
Address Error Exception
Cause
The Address Error exception occurs when an attempt is made to execute
one of the following:
• load or store a doubleword that is not aligned on a doubleword
boundary
• load, fetch, or store a word that is not aligned on a word
boundary
• load or store a halfword that is not aligned on a halfword
boundary
• reference the kernel address space from User or Supervisor
mode
• reference the supervisor address space from User mode
This exception is not maskable.
Processing
The common exception vector is used for this exception. The AdEL or
AdES code in the Cause register is set, indicating whether the instruction
caused the exception with an instruction reference, load operation, or store
operation shown by the EPC register and BD bit in the Cause register.
When this exception occurs, the BadVAddr register retains the virtual
address that was not properly aligned or that referenced protected
address space. The contents of the VPN field of the Context and EntryHi
registers are undefined, as are the contents of the EntryLo register.
The EPC register contains the address of the instruction that caused the
exception, unless this instruction is in a branch delay slot. If it is in a
branch delay slot, the EPC register contains the address of the preceding
branch instruction and the BD bit of the Cause register is set as indication.
Address Error exception processing is shown in Figure 5-17.
Servicing
The process executing at the time is handed a UNIX SIGSEGV
(segmentation violation) signal. This error is usually fatal to the process
incurring the exception.
