Chapter 12
376 MIPS R4000 Microprocessor User's Manual
Table 12-25 Processor Data Identifier Encoding of SysCmd(7:3)
Table 12-26 External Data Identifier Encoding of SysCmd(7:3)
SysCmd(7) Last Data Element Indication
0 Last data element
1 Not the last data element
SysCmd(6) Response Data Indication
0 Data is response data
1 Data is not response data
SysCmd(5) Good Data Indication
0 Data is error free
1 Data is erroneous
SysCmd(4:3) Reserved
SysCmd(7) Last Data Element Indication
0 Last data element
1 Not the last data element
SysCmd(6) Response Data Indication
0 Data is response data
1 Data is not response data
SysCmd(5) Good Data Indication
0 Data is error free
1 Data is erroneous
SysCmd(4) Data Checking Enable
0 Check the data and check bits
1 Do not check the data and check bits
SysCmd(3) Reserved
