MIPS R4000 Microprocessor User's Manual A-21
CPU Instruction Set Details
Format:
BCzT offset
Description:
A branch target address is computed from the sum of the address of the
instruction in the delay slot and the 16-bit offset, shifted left two bits and
sign-extended. If the coprocessor z’s condition signal (CpCond) is true,
then the program branches to the target address, with a delay of one
instruction.
Because the condition line is sampled during the previous instruction,
there must be at least one instruction between this instruction and a
coprocessor instruction that changes the condition line.
Operation:
*See the table “Opcode Bit Encoding” on next page, or “CPU Instruction
Opcode Bit Encoding” at the end of Appendix A.
BCzT
Branch On Coprocessor z True
5
16 15
BC
31 2526
COPz
6
0
16
offsetBCT
21 20
5
0 1 0 0 x x* 0 1 0 0 0 0 0 0 0 1
BCzT
T: target ← (offset
15
)
14
|| offset || 0
2
32 T–1: condition ← COC[z]
T+1: if condition then
PC ← PC + target
endif
T: target ← (offset
15
)
46
|| offset || 0
2
64 T–1: condition ← COC[z]
T+1: if condition then
PC ← PC + target
endif
