MIPS R4000 Microprocessor User's Manual A-123
CPU Instruction Set Details
Format:
OR rd, rs, rt
Description:
The contents of general register rs are combined with the contents of
general register rt in a bit-wise logical OR operation. The result is placed
into general register rd.
Operation:
Exceptions:
None
OR
Or
31 2526 2021 1516
SPECIAL rs rt
655
rd 0 OR
55 6
11 10 6 5 0
0 0 0 0 0 0 0 0 0 0 0 1 0 0 1 0 1
OR
32, 64 T: GPR[rd] ← GPR[rs] or GPR[rt]
