MTBDWT_CTRL field descriptions (continued)
Field Description
MTBDWT_CTRL[26] = NOEXTTRIG = 1, external match signals are not supported
MTBDWT_CTRL[25] = NOCYCCNT = 1, cycle counter is not supported
MTBDWT_CTRL[24] = NOPRFCNT = 1, profiling counters are not supported
MTBDWT_CTRL[22] = CYCEBTENA = 0, no POSTCNT underflow packets generated
MTBDWT_CTRL[21] = FOLDEVTENA = 0, no folded instruction counter overflow events
MTBDWT_CTRL[20] = LSUEVTENA = 0, no LSU counter overflow events
MTBDWT_CTRL[19] = SLEEPEVTENA = 0, no sleep counter overflow events
MTBDWT_CTRL[18] = EXCEVTENA = 0, no exception overhead counter events
MTBDWT_CTRL[17] = CPIEVTENA = 0, no CPI counter overflow events
MTBDWT_CTRL[16] = EXCTRCENA = 0, generation of exception trace disabled
MTBDWT_CTRL[12] = PCSAMPLENA = 0, no periodic PC sample packets generated
MTBDWT_CTRL[11:10] = SYNCTAP = 0, no synchronization packets
MTBDWT_CTRL[9] = CYCTAP = 0, cycle counter is not supported
MTBDWT_CTRL[8:5] = POSTINIT = 0, cycle counter is not supported
MTBDWT_CTRL[4:1] = POSTPRESET = 0, cycle counter is not supported
MTBDWT_CTRL[0] = CYCCNTENA = 0, cycle counter is not supported
19.32.2 MTB_DWT Comparator Register (MTBDWT_COMPn)
The MTBDWT_COMPn registers provide the reference value for comparator n.
Address: F000_1000h base + 20h offset + (16d × i), where i=0d to 1d
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
COMP
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
MTBDWT_COMPn field descriptions
Field Description
31–0
COMP
Reference value for comparison
If MTBDWT_COMP0 is used for a data value comparator and the access size is byte or halfword, the data
value must be replicated across all appropriate byte lanes of this register. For example, if the data is a
byte-sized "x" value, then COMP[31:24] = COMP[23:16] = COMP[15:8] = COMP[7:0] = "x". Likewise, if the
data is a halfword-size "y" value, then COMP[31:16] = COMP[15:0] = "y".
