Table 3-20. DMA request sources - MUX 0 (continued)

Source

number

Source module Source description Async DMA

capable

8 Reserved —

9 Reserved —

10 Reserved —

11 Reserved —

12 Reserved —

13 Reserved —

14 Reserved —

15 Reserved —

16 SPI0 Receive

17 SPI0 Transmit

18 SPI1 Receive

19 SPI1 Transmit

20 Reserved —

21 Reserved —

22 I

C0 —

23 I

C1 —

24 TPM0 Channel 0 Yes

25 TPM0 Channel 1 Yes

26 TPM0 Channel 2 Yes

27 TPM0 Channel 3 Yes

28 TPM0 Channel 4 Yes

29 TPM0 Channel 5 Yes

30 Reserved —

31 Reserved —

32 TPM1 Channel 0 Yes

33 TPM1 Channel 1 Yes

34 TPM2 Channel 0 Yes

35 TPM2 Channel 1 Yes

36 Reserved —

37 Reserved —

38 Reserved —

39 Reserved —

40 ADC0 — Yes

41 Reserved —

42 CMP0 — Yes

43 Reserved —

44 Reserved —

45 DAC0 —

46 Reserved —

Table continues on the next page...

Chapter 3 Chip Configuration

KL25 Sub-Family Reference Manual, Rev. 3, September 2012

Freescale Semiconductor, Inc. 65
