Broadcast Pix BPswitch - Page 172

BPswitch Operators Manual
172 / 413
composition, as if there was a camera
operator.
10.
To reset all the scaling and
positioning to return to the default
state, press the Reset button, as
shown on the right.
11.
As various moves have been scaled
and positioned according, moves can
be saved for future recall. Click on the
Save drop down menu.
12.
Select Save A, Save B, Save C or
Save D, as shown on the right.
To recall moves for an angle:
1.
Select the desired Angle to create
moves for in the Virtual Angles pane, the
Angle will highlight blue, as shown on
the right.
2.
Select the desired move rate using the
predefined speeds of Cut (0), F (2
seconds), M (5 seconds) or S (10
seconds), the button will illuminate blue,
as shown on the right.
3.
To enter a custom speed, type a number
in the Secs. text field from 0 to 999
seconds. After entering a number, press
enter on the keyboard.
4.
Click on the Moves: A, B, C or D button.
The Virtual Set will move from the
current position to the saved move at
the selected rate.
To control Virtual Studios from the Control Panel:
Most of the controls and settings from Fluent Controls can also be controlled from
a
physical panel or SoftPanel. This provides for a more tactile experience and a
quick way to
