Programmer’s Guide BCM5722
10/15/07
Broadcom Corporation
Document 5722-PG101-R Endian Control (Byte and Word Swapping) Page 146
WORD SWAP DATA AND BYTE SWAP DATA BITS
The Word Swap Data, and Byte Swap Data bits effect how packet data is ordered on the PCI bus. These only affect how
packet data is ordered, and do not affect non-frame data (i.e., buffer descriptors, statistics block, etc.). In other words, these
bits effect how data is transferred to/from host send/receive buffers.
For example, if BCM5722 Ethernet controller were to receive a packet that had the following byte order:
Where:
• D1–D6 consists of the packet’s destination address (Byte D0 is the first byte on the wire);
• S1–S6 is the source address;
• T1–T2 is the Ethernet type/length field;
• IP1–IP2 are the first two bytes of the IP header which immediately follow the type/length field.
The packet would be stored internally in big endian format:
However, when the data gets transferred across PCI, there could be confusion about the correct byte ordering because PCI
is Little Endian whereas BCM5722 Ethernet controller is a Big Endian device. So, in order to provide flexibility for different
host processor/memory architectures, BCM5722 Ethernet controller can order this data on PCI in four different ways
depending on the settings of the Word Swap Data, and Byte Swap Data bits. The below figures illustrate how data would
appear on the PCI AD[63:0] pins depending on the settings of those swap bits:
01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F 10
D1 D2 D3 D4 D5 D6 S1 S2 S3 S4 S5 S6 T1 T2 IP1 IP2
Table 60: Big-Endian Internal Packet Data Format
B0 B1 B2 B3 B4 B5 B6 B7
63–56 55–48 47–40 39–32 31–24 23–16 15–8 7–0
D1 D2 D3 D4 D5 D6 S1 S2
S3 S4 S5 S6 T1 T2 IP1 IP2
