Programmer’s Guide BCM5722
10/15/07
Broadcom Corporation
Document 5722-PG101-R Host Coalescing Control Registers Page 300
NIC DIAGNOSTIC SEND BD CONSUMER INDEX REGISTER (OFFSET 0X3CC0–0X3CC3)
This register keeps track of the NIC local copy of the send BD ring consumer index (not the host copy which is DMAed by
the Host Coalescing engine to the host). This is shared between the Send BD Initiator and the Host Coalescing state
machines.
Note: The programmer should not write to this register—it is for internal use only to aid with debugging and
diagnostics.
Table 289: NIC Send BD Consumer Index (Offset 0x3CC0)—BCM5722, BCM5755, BCM5755M, BCM5756M,
BCM5757, BCM5754, BCM5787 Only
Bit Field Description Init Access
31:16 Reserved – 0 RO
15:0 NIC Send BD
Consumer Index
NIC Send BD Consumer Index R/W
Table 290: NIC Send BD Consumer Index (Offset 0x3CC0)—BCM5906 Only
Bit Field Description Init Access
31:25 Reserved – 0 R/O
24:16 NIC Send ISO BD
Consumer Index
NIC Send ISO BD Consumer Index 0 R/W
15:9 Reserved – 0 R/O
8:0 NIC Send data BD
Consumer Index
NIC Send data BD Consumer Index 0 R/W
