1000BASE-X AUTO-NEGOTIATION DEBUG (PHY_ADDR = 0X1, REG_ADDR = 1CH, SHADOW
11010B)
Write Enable
During a write to this register, setting LED 1000BASE-X Auto-negotiation Debug register bit 15 to a 1 allows writing to bits
[7:0] of this register. For reading the values of bits [9:0], perform an MDIO write with bit 15 set to a 0 and preferred shadow
values in bits [14:10]. The next MDIO read of register address 1Ch contains the preferred shadow register values in bits [9:0].
Shadow Register Selector
Bits [14:10] of this register must be set to 11010 to enable read/write to the 1000BASE-X Auto-negotiation Debug register.
Consistency Mismatch
Bit 9 of 1000BASE-X Auto-negotiation Debug register indicates a consistency mismatch occurred since last read.
RUDI Invalid
Bit 8 of 1000BASE-X Auto-negotiation Debug register indicates a RUDI (Rx_UnitData Indicate, specified in IEEE 36.2.5.1.6)
invalid detected since last read.
Table 527: 1000BASE-X Auto-Negotiation Debug Register (Address 1Ch, Shadow Value 11010)
Bit Field Description Init Access
15 Write Enable • 1 = Write bits [9:0].
• 0 = Read bits [9:0].
0R/W
14:10 Shadow Register Selector 11010 = 1000BASE-X Auto-negotiation Debug register. 11010 R/W
9 Consistency Mismatch
• 1 = Consistency mismatch occurred since last read.
• 0 = No consistency mismatch occurred since last read.
0RO
LH
8 RUDI Invalid
• 1 = RUDI invalid detected since last read.
• 0 = No RUDI invalid detected since last read.
0RO
LH
7Comma Detected
• 1 = Comma detected since last read.
• 0 = No comma detected since last read.
0RO
LH
6 AN_Sync_Status
• 1 = AN_sync_status has not failed since last read.
• 0 = AN_sync_status failed since last read.
0RO
LH
5 Idle Detect State
• 1 = Idle detect state entered since last read.
• 0 = Idle detect state has not been entered since last read.
0RO
LH
4 Complete Acknowledge
State
• 1 = Complete acknowledge state entered since last read.
• 0 = Complete acknowledge state has not been entered since
last read.
0RO
LH
3 Acknowledge Detect State
• 1 = Acknowledge detect state entered since last read.
• 0 = Acknowledge detect state has not been entered since last
read.
0RO
LH
2 Ability Detect State
• 1 = Ability detect state entered since last read.
• 0 = Ability detect state has not been entered since last read.
0RO
LH
1 Error State
• 1 = Error state entered since last read.
• 0 = Error state has not been entered since last read.
0RO
LH
0 AN_Enable State
• 1 = AN_enable state entered since last read.
• 0 = AN_enable state has not been entered since last read.
0RO
LH
