Programmer’s Guide BCM5722
10/15/07
Broadcom Corporation
Document 5722-PG101-R Ethernet MAC Control Registers Page 242
-
0x488–0x48b Recv BD Rules Control Register 1 0x00000000
0x48c–0x48f Recv BD Rules Mask/Value Register 1 0x00000000
0x490–0x493 Recv BD Rules Control Register 2 0x00000000
0x494–0x497 Recv BD Rules Mask/Value Register 2 0x00000000
0x498–0x49b Recv BD Rules Control Register 3 0x00000000
0x49c–0x49f Recv BD Rules Mask/Value Register 3 0x00000000
0x4a0–9x4a3 Recv BD Rules Control Register 4 0x00000000
0x4a4–0x4a7 Recv BD Rules Mask/Value Register 4 0x00000000
0x4a8–0x4ab Recv BD Rules Control Register 5 0x00000000
0x4ac–0x4af Recv BD Rules Mask/Value Register 5 0x00000000
0x4b0–0x4b3 Recv BD Rules Control Register 6 0x00000000
0x4b4–0x4b7 Recv BD Rules Mask/Value Register 6 0x00000000
0x4b8–0x4bb Recv BD Rules Control Register 7 0x00000000
0x4bc–0x4bf Recv BD Rules Mask/Value Register 7 0x00000000
0x4c0–0x4ff Reserved 0x00000000
0x500–0x503 Receive Rules Configuration Register 0x00000000
0x504–0x507 Low Watermark Maximum Receive Frames Register 0x00000000
0x508–0x51f Reserved X
0x520–0x52f Mac Hash Table Register 0
0x530–0x62f Reserved X
0x630–0x66f Indirection Table Registers 0–15 0
0x670–0x697 Hash Key Registers 0–9 0
0x698–0x69f Reserved X
0x6a0–0x6a3 Receive MAC Programmable IPv6 Extension Header Register
0x6a4–0x7ff Reserved X
0x800–0x87f Tx MAC Statistics Registers 0x00000000
0x880–0x8bb Rx MAC Statistics Registers 0x00000000
0x8bc–0xbff Reserved 0x00000000
Table 188: Ethernet MAC Control Registers—BCM5722, BCM5755, BCM5755M, BCM5756M, BCM5757, BCM5754,
BCM5787 Only (Cont.)
Offset Registers Init
