Broadcom BCM5722 - Page 542

BCM5722 Programmer’s Guide
10/15/07
Broadcom Corporation
Page 483 Transceiver Registers (BCM5906/BCM5906M) Document 5722-PG101-R
24(18h) Auxiliary Control/Status Register 003Xh
25(19h) Auxiliary Status Summary Register 0000h
26(1Ah) Interrupt 0F0Xh
27(1Bh) Auxiliary Mode 2 Register 008Ah
28(1Ch) 10Base-T Auxiliary Error and General Status
Register
002Xh
29(1Dh) Auxiliary Mode Register X004h
30(1Eh) Auxiliary Multi PHY Register 0000h
31(1Fh) Broadcom Test Register 000Bh
16(10h) Miscellaneous Control Register 0000h
17(11h) Reserved 0000h
18(12h) Reserved 0000h
19(13h) Cable Diagnostic Register 0000h
20(14h) Link Diagnostic Register 000Xh
21(15h) Reserved 0000h
22(16h) Reserved 0000h
23(17h) Reserved 0000h
24(18h) Reserved 003Ah
25(19h) Reserved 0000h
26(1Ah) Reserved 3000h
27(1Bh) Auxiliary Status 2 Register 0001h
28(1Ch) Auxiliary Status 3 Register 0000h
29(1Dh) Auxiliary Mode 3 Register 0004h
30(1Eh) Auxiliary Status 4 Register 0000h
Table 537: MII Register Summary (Cont.)
Register Description Default
