IBM TS3310 User Manual

Table 7-1. Methods of Capturing Drive Logs (continued)
Type of Error Log Operator Panel Web User Interface SCSI/Fibre Interface
Drive Not available Service
Library->Capture
Drive Log
v “Using the ITDT
SCSI Firmware
Update, Dump
Retrieval and
Drive Test Tool”
on page 7-27
v NTUTIL or
TapeUTIL (For
more information
on these tools,
refer to the device
driver
documentation
shipped with your
library.)
Capturing a Library Log using the Service Port
Note: Ensure your browser pop-up blocker is disabled when downloading the Log
file. Pop-up blockers will prevent the File Download dialog box from
opening.
1. Perform the steps in “Using the Service Port” on page 7-9.
2. From the Web User Interface, select Service Library → Capture Library Logs.
3. Click the Download the file using the browser button to begin downloading
the library log.
4. Click the Capture Log button.
1
2
4
5
6
a66ug014
3
Chapter 7. Service Procedures 7-11

IBM TS3310 Specifications

General

Form Factor	Rack-mountable
Tape Technology	LTO Ultrium
Product Type	Tape Library
Interface	Fibre Channel
Expansion	Expandable with additional modules
Supported Tape Technology	LTO Ultrium 5, LTO Ultrium 6
Weight	120 lb (54.4 kg) (fully configured)
Power Supply	Dual redundant power supplies
Operating Temperature	41°F to 95°F (5°C to 35°C)
Non-operating Temperature	-40°F to 140°F (-40°C to 60°C)
Humidity	20% to 80% non-condensing
