Chapter 10. Parts List
Field Replaceable Unit (FRU) parts list
FRU Type Description
FRU Part
Number
Assemblies Display (Operator Panel) 23R6174
I/O Station for control module 23R2587
I/O Station for 9U expansion module 23R2588
Expansion module enclosure 23R6168
I/O Station Lock Assembly 23R2589
Y-axis Assembly (Below Control Module S/N 15000) 23R6186
Y Motor (Below Control Module S/N 15000) 23R7285
Picker with Bar Code Scanner (Below Control Module S/N 15000) 23R6171
Cable Spool 23R2583
M2 Robot Assembly (Above Control Module S/N 15000) 45E6348
M2 Picker Assembly (Above Control Module S/N 15000) 45E6351
Power Button 23R3348
Front Bezels for control module 23R2597
Front Bezels for 9U expansion module 23R2598
Miscellaneous 5U drive power overload fuse 23R6178
9U drive power overload fuse 23R6185
Storage magazine (8 slot with fiducial) 23R7286
Storage magazine (16 slot with fiducial) 23R7287
I/O Station magazine 23R3640
Gear Racks (front and back) for L5B control module 23R9476
Gear Racks for E9U expansion module 23R9477
Kits CAN Bus Tool Kit 46X1438
Kit 1, Door Interlock Switch 23R6179
Kit 2, Power Switch/LED Board and Cable 23R6180
Kit 3, Internal Cables and Boards, 5U Control Module 23R6181
Kit, Misc. parts ('Y' home flag, door Inlk., cover screws) 95P4564
Kit, I/O Safety Flap, 5U Control Module 95P5424
Kit, I/O Safety Flap, 9U Expansion Module 95P5425
Customer Replaceable Unit (CRU) parts list
Important: This library has Tier 1 CRUs (customer replaceable units). These CRUs
are parts of the library that must be added, removed, and replaced by
the customer. If a customer chooses to have the CRU added or
removed/replaced by an IBM Service Representative, there will be a
charge for the service.
© Copyright IBM Corp. 2005, 2010 10-1
|||
