Replacing the Access Door Bezel
1. To install the new Access Door bezel, perform the steps in “Removing the
Access Door Bezel” on page 8-27 in reverse order.
2. Copy the serial number on the label in the lower left corner of the old Access
Door bezel onto the blank label supplied with the new Access Door bezel, then
apply the new serial number label in the recess located in the lower left corner
on the new Access Door bezel.
3. Perform “Returning a Library or Library Module to Normal Operations after
Repairs” on page 8-4.
Operator Panel
The Operator Panel enables you to control the library using the LCD screen located
on the Control Module (CM) Access Door.
a66mi087
1
1
1
Figure 8-25. Expansion module Access Door screw locations
8-28 TS3310 Tape Library Maintenance Information

IBM TS3310 Specifications

General

Form Factor	Rack-mountable
Tape Technology	LTO Ultrium
Product Type	Tape Library
Interface	Fibre Channel
Expansion	Expandable with additional modules
Supported Tape Technology	LTO Ultrium 5, LTO Ultrium 6
Weight	120 lb (54.4 kg) (fully configured)
Power Supply	Dual redundant power supplies
Operating Temperature	41°F to 95°F (5°C to 35°C)
Non-operating Temperature	-40°F to 140°F (-40°C to 60°C)
Humidity	20% to 80% non-condensing
