Library Control Blade (LCB)
1 Module-to-module
terminator
4 Module-to-module cable
2 Ethernet cable 5 Ethernet port (for Service use)
3 Latches 6 Serial port (for Service use)
1
2
4
5
6
a66ug014
3
Figure 3-13. Library Control Blade (external library view)
