Cable Spool Assembly
Table 3-1. Cable Spool Assembly components
1 Plastic
guide peg
2 Spooler flat
cable
handle
3 Terminal
Board
4 IBM Part Number
The cable spool assembly in the left was from initial release (2005), the one on the
right is a version from 2007. Although they look different, they are completely
interchangeable, and the remove/replace procedures are the same. Either spool
may be in the library and you may receive either as a Field Support Unit (FRU).
The part number for both is the same. See “Cable Spool Assembly” on page 8-100.
a66mi028
3
4
2
1
Figure 3-12. Cable spool assembly
Chapter 3. Library Components 3-9

IBM TS3310 Specifications

General

Form Factor	Rack-mountable
Tape Technology	LTO Ultrium
Product Type	Tape Library
Interface	Fibre Channel
Expansion	Expandable with additional modules
Supported Tape Technology	LTO Ultrium 5, LTO Ultrium 6
Weight	120 lb (54.4 kg) (fully configured)
Power Supply	Dual redundant power supplies
Operating Temperature	41°F to 95°F (5°C to 35°C)
Non-operating Temperature	-40°F to 140°F (-40°C to 60°C)
Humidity	20% to 80% non-condensing
