thumbscrew (1 in Figure 8-70) to disconnect the cable spool.
7. Remove any media that is in the picker.
8. Carefully lower the Cable Spool connector (3 in Figure 8-71 on page 8-69)
and hook it around the black plastic guide peg (2 in Figure 8-71 on page
8-69).
a66mi123
1
2
Figure 8-70. Thumb screw securing Cable Spool
