IBM TS3310 User Manual

Chapter 4. User Interfaces
“Operator Panel”
“Web User Interface (UI)” on page 4-7
“User Privileges” on page 4-10
The library has a local interface, the Operator Panel, and a remote Web User
Interface (UI).
The Operator Panel is located on the front door of the control module (CM) and
allows users to work locally on the library via the user interface. The Web UI
allows users to view and perform some library functions from remote sites and is
best viewed using Internet Explorer 5.0 or higher, or Firefox 1.0 or higher.
Operator Panel
The Operator Panel is physically attached to the front door of the control module
(CM). The user interface appears on the touchscreen LCD display of the Operator
Panel for executing basic library management functions. Audible feedback, such as
"key click" sounds, are generated when a user touches a button on the touchscreen.
Operator Panel Login Screen
Note: For firmware versions prior to 585G, when LDAP (Lightweight Directory
Access Protocol) is enabled, the login screen gives the user a choice between
a66ug028
Figure 4-1. Operator Panel Login screen for firmware versions prior to 585G
© Copyright IBM Corp. 2005, 2010 4-1
|
|
|
|
|
|
|
|

IBM TS3310 Specifications

General

Form Factor	Rack-mountable
Tape Technology	LTO Ultrium
Product Type	Tape Library
Interface	Fibre Channel
Expansion	Expandable with additional modules
Supported Tape Technology	LTO Ultrium 5, LTO Ultrium 6
Weight	120 lb (54.4 kg) (fully configured)
Power Supply	Dual redundant power supplies
Operating Temperature	41°F to 95°F (5°C to 35°C)
Non-operating Temperature	-40°F to 140°F (-40°C to 60°C)
Humidity	20% to 80% non-condensing
