IBM TS3310

a66mi082
2
1
Figure 8-27. Connector on the back of the I/O Station locking mechanism
a66mi083
2
3
1
Figure 8-28. Connector between the storage column 4 magazine and Library Control Blade (top cover removed)
8-30 TS3310 Tape Library Maintenance Information
