Powering the Library ON
1. Connect all power cords to their electrical source.
2. Toggle the power switch on each power supply to the ON (|) position.
3. Press the power switch located on the front door of the library's control module
(CM). The Operator Panel will display "Working" while the library performs
the Power On Self Test (POST). The POST takes several minutes.
4. When the library is ready for operations, the login screen displays on the
Operator Panel. See “Operator Panel Login Screen” on page 4-1.
Restarting the Library
1. Using the library's Operator Panel, ensure that no applications are accessing the
library. If a Progress Screen is open, wait until it closes before attempting to
restart the library.
2. Take the entire library (including all drives and logical libraries) offline.
v To take each logical library offline using the Operator Panel, select
Operations → Logical Library Mode.
v To take each drive offline using the Operator Panel, select Operations →
Change Drive Mode.
3. From the Operations menu, click Shutdown. The System Shutdown window
appears.
4. In the System Shutdown window, select Restart and click Apply.
5. In the System Restart Confirmation window, click Yes.
6. Bring the entire library (including all drives and logical libraries) online.
v Bring the desired logical libraries back online using the Operator Panel by
selecting Operations → Logical Library Mode.
v Bring each drive online using the Operator Panel by selecting Operations →
Change Drive Mode.
Manually Recover Cartridge from Picker
The procedure to manually recover a cartridge from a Picker is similar for both the
Y-axis/Picker Assembly and the M2 Robot Assembly.
1. Manually rotate the Picker to gain access to the appropriate component to eject
the cartridge.
v In the Y-axis/Picker Assembly, access the three drive gears, as shown in
Figure 7-18 on page 7-41.
7-40 TS3310 Tape Library Maintenance Information
