Door and Display Block
Power System Block Diagram
Drive Sled Interconnect Board (DSIB)
a66mi03
4
Rear Panel Switch
Front Panel Power
Enable Switch
Load Sharing 48 V Power Supply
Input: 100-260V AC
Load Sharing 48 V Power Supply
Input: 100-260V AC
12C PS Monitor
Logic and
Servo Circuit
Protection
Drive Circuit
Protection
48V
48V
48V
48V
a66mi070
C-12 TS3310 Tape Library Maintenance Information
