Gear Rack
1 Front gear rack 2 Rear gear rack
Y-Axis/Picker Assembly and M2 Robot Assembly
This section depicts the Y-Axis/Picker Assembly and the M2 Robot Assembly.
Libraries contain either one or the other of these components.
a66mi050
1
2
Figure 3-8. Gear racks inside the library
3-6 TS3310 Tape Library Maintenance Information
