IBM TS3310

2. Move the Picker into the control module.
a. Gently push the Picker up until it is in the control module.
b. Engage the Picker locking mechanism (1 in Figure 8-1).
a66mi053
1
Figure 8-1. Picker locking mechanism
8-6 TS3310 Tape Library Maintenance Information
