Detection Scenario Robotics firmware reports a specific hardware error identifying the Imager
component of the Picker assembly as the source.
Root Causes
1. Obstructions in the view path of the robot Imager.
2. Electrical hardware failure.
Possible FRUs
v Picker Assembly (if Model 1 or Model 2 robot is installed)
v Robot Assembly (if Model 2 robot is installed)
Resolution Perform “DR092: Resolve Robotics Hardware Error - Scanner” on page 6-88.
T127: Robotics Communication Error
Description This ticket occurs with Model 2 robots only.
GUI Description: The library controller firmware lost communication with
the robotics subsystem.
Explanation: The library is not able to communicate with the Model 2
robotics subsystem. This ticket is generated if the library had previously
established a communication link with the robotics subsystem, but that link
has now been lost and cannot be reestablished.
Detection Scenario The library firmware did establish communication with the robotics
subsystem but encountered a communication failure during operation and
communication could not be reestablished.
Root Causes
1. Damaged module terminator or module-to-module cable with bent or
broken pins.
2. An intermittent door-open condition disconnecting power from the robot.
3. A cable spool or connection problem.
4. A picker assembly hardware failure.
5. A Y-carriage assembly connection problem.
6. A robot controller board hardware or software failure.
7. An LCB serial communication link failure.
Possible FRUs
v Cable Spool
v Robot Assembly (replace entire unit)
Resolution Perform “DR093: Resolve Robotics Communication Error” on page 6-88.
T128: Incompatible Robot Installation
Description GUI Description: The library control firmware detected that an incompatible
robot is installed.
Explanation: The library has an incompatible robot installed. This may
happen when a GA-style (Model 1) robot is replaced with the Model 2 robot,
or vice versa.
Detection Scenario Library firmware detects a change in robot model, which is incompatible
with the current library configuration.
Root Causes The robot was replaced with an incompatible robot type.
Possible FRUs
v Robot Assembly
Resolution Perform “DR094: Resolve Incompatible Robot Installed” on page 6-88.
6-52 TS3310 Tape Library Maintenance Information
